Proje Açıklamaları
23-V-101 PROCESS AIR RECEIVER - 1391/1: ID1600mm, t12mm, L4900mm
23-V-102 PROCESS WATER RECEIVER - 1391/2: ID1400mm, t10mm, L3400mm, paslanmaz
23-V-103 KNOCK OUT DRUM - 1391/3: ID2000mm, t13mm, L5900mm
23-V-104 HOT OIL EXPANSION VESSEL - 1391/4: ID1600mm, t10mm, L3550mm
23-V-105 HOT OIL COLLECTION VESSEL - 1391/5: ID2500mm, t12mm, L6600mm
23-V-107 FUEL GAS KO DRUM - 1391/6: ID900mm, t12mm, L1830mm
23-V-108 FLUSHING OIL VESSEL - 1391/7: ID3500mm, t15mm, L6400mm
Tarih: 2017
Teslim Yeri: Socar Heydar Aliyev Oil Refinery / Azerbaycan
Dizayn Kodu: ASME Section VIII Div.1
ASME: U Stamp
PED: Yok
ATEX: Yok
